Cooler Master MWE 750W Gold V2 12VHPWR A/UK Power Supply - Black
COOLER MASTER MWE 750 GOLD V2 - 750W 80 Plus Gold ATX 3.0 Fully Modular Power Supply Unit - Black
Level Up Your Power
Cooler Master presents the MWE Gold V2 ATX 3.0 Ready featuring high power, ultra-silent performance with exceptional efficiency and reliability.
ATX 3.0 Support & a Durable 12VHPWR Adapter Cable
Includes ATX 3.0 support and a 90-degree 12+4pin (12VHPWR) PCIe 5.0 connector with higher electrical durability and three 8-pin connectors with improved safety, capable of bringing up to 600W to your GPU.
High Temperature Resilience
A 50°C operating temperature and high quality Japanese capacitors allow for pushing your machine to the limits.
Certified Efficiency
The MWE Gold V2 ATX 3.0 Ready is certified to achieve more than 90% efficiency at typical loads.
Fully Modular Cabling
Modular cabling reduces clutter, increases airflow, and improves overall thermal performance.
Three 8-pin Connectors
Up to 600W of power is split between three 8-pin connectors, providing enhanced safety.
Specifications
-
Model : MPE-7501-AFAAG-3
-
ATX Version : ATX 12V Ver. 3.0
-
PFC : Active PFC
-
Input Voltage : 100-240V
-
Input Current : 10-5A
-
Input Frequency : 50-60Hz
-
Dimensions (L x W x H) : 160 x 150 x 86 mm
-
Fan Size : 120mm
-
Fan Bearing : HDB
-
Efficiency : ≥90% @ Typical Load
-
80 PLUS Rating : 80 PLUS Gold
-
ErP 2014 Lot 3 : Yes
-
Operating Temperature : 0-50°C
-
Power Good Signal : 100 - 150 ms
-
Hold Up Time : ≥ 16ms
-
MTBF : >100,000 Hours
-
Protections : UVP / OVP / OPP / OTP / SCP / OCP
-
Regulatory : TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA
-
ATX 24 Pin Connectors : 1
-
EPS 4+4 Pin Connectors : 1
-
EPS 8 Pin Connector : 1
-
SATA Connectors : 12
-
Peripheral 4 Pin Connectors : 4
-
PCI-e 6+2 Pin Connectors : 4
-
12VH PWR Connector : 1 (1 to 3)
-
Category : Above 750W
-
Series : MWE Gold Series
-
Modular : Fully Modular
-
Form Factor : ATX
-
80 Plus Efficiency : Gold
-
Watts : 750W
